Integra DRX 2.4 7.2 Ch 8K Audio Video Reciever

8K Video Upscaling

The DRX 2.4 8k AV receiver is equipped with advanced video processing capabilities, allowing it to upscale lower-resolution content to stunning 8K quality. This ensures that you can enjoy the highest level of detail and clarity in your video content, even from older sources.

5.1.2 Channel Configuration

The Integra DRX 2.4 AV receiver supports a 5.1.2 channel speaker setup, providing a versatile and immersive audio experience. With five main channels, a subwoofer, and two height channels for overhead sound, you can enjoy dynamic audio for both movies and music.

Dolby Atmos and DTS:X Support

The DRX 2.4 from Integra is compatible with the latest audio formats, including Dolby Atmos and DTS: X. These formats deliver three-dimensional, object-based audio, allowing sound to move freely around you, creating a more realistic and immersive listening experience.

Wireless Connectivity

With built-in Wi-Fi and Bluetooth capabilities, this receiver offers convenient wireless connectivity for streaming music and content from your smartphone, tablet, or other devices. You can easily access your favorite streaming services and playlists.

Multi-Zone Audio

This AV receiver from Integra supports multi-zone audio, allowing you to enjoy different audio sources in separate rooms or zones of your home. This feature is perfect for setting up music in one room while watching a movie in another, all controlled from a central location.

Specifications

Amplifier Section

• Power Output Front L/R: 170 W/Ch at 6 Ohms, 1 kHz, 10%, 1 Channel Driven, 80 W/Ch at 8 Ohms, 20 Hz–20 kHz, 0.08%, 2 Channels Driven, FTC
• Dynamic Power: 160 W (3 Ohms, Front),125 W (4 Ohms, Front), 85 W (8 Ohms, Front)
• Input Sensitivity and Impedance: 200 mV rms/47 k-Ohms (Line/Unbalance), 3.5 mV rms/47 k-Ohms (Phono MM)
• THD+N (Total Harmonic Distortion + Noise) : 0.08% (20 Hz–20 kHz, Half Power)
• Rated RCA Output Level and Impedance: 1 V rms/470 Ohms (Pre-out/Subwoofer Pre-out), 200 mV rms/470 k-Ohms (Zone B Line-out)
• Phono Overload: 70 mV (MM, 1 kHz, 0.5%)
• Frequency Response: 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
• Tone Control: ±10 dB, 20 Hz (Bass), ±10 dB, 20 kHz (Treble)
• Signal-to-Noise Ratio: 106 dB (IHF-A, Line), 80 dB (IHF-A, Phono)
• Speaker Impedance: 4 Ohms–16 Ohms


Tuner Section

• Tuning Frequency Range: FM 87.5 MHz–107.9 MHz, AM 530 kHz–1,710 kHz
• FM/AM Preset Memory: 40 Stations


General

• Power Supply: AC 120 V~, 60 Hz
• Power Consumption: 460 W
• Standby Power Consumption: 0.1 W
• Dimensions (W x H x D): 17 1/8˝ x 6 7/8˝ x 14 13/16˝ (435 x 174 x 376.5 mm)
• Weight: 21.2 lbs. (9.6 kg)


Carton

• Dimensions (W x H x D): 22 1/16˝ x 12˝ x 18 3/8˝ (560 x 305 x 467 mm)
• Weight: 21.2 lbs. (9.6 kg)
