Description
Body Material Metal
Case/Package Metal
Color Black, Silver
Contact Material Brass
Contact Plating Silver
Contact Resistance 3mR
Current Rating 15A
Flammability Rating UL94 V-0
Gender Male
Height 31mm
Insulation Resistance 1GR
Length 26mm
Max Current Rating 15A
Max Operating Temperature 75°C
Min Operating Temperature -25°C
Mount Panel
Number of Contacts 3
Number of Ports 1
Number of Positions 3
Orientation Straight
Plating Nickel
Ratings IP40
Reach SVHC Compliant No
RoHS Compliant Yes
Series AC SERIES
Termination Solder
Voltage Rating 133V
Voltage Rating (DC) 133V
